DELTA DVP-10PM

Product Description

Applications

Used for 2-axis servo positioning control, material cutting machine (high-speed servo control), crane operations, material clipper controlled by the servo.

Specifications

1. MPU points: 24
2. Max. I/O points: 256
3. Program capacity: 64k steps
4. Built-in hardware digital filter for counting
5. 6 high-speed counters (O.C. 200kHz*4, differential 200kHz*2), supporting U/D, U/D Dir, A/B, 4A/B counting modes
6. 4 differential 1MHz outputs, supporting U/D, U/D Dir, A/B output modes
7. Supports 1-speed (immediate stop after the mark arrives), 2-speed, zero return, MPG and single axis function
8. Highly accurate PWM 200kHz output, resolution 0.3%
9. Electronic gear function
10. 8 high-speed captures (mark correction, frequency measurement), comparative output, mark/mask function (for bag making)
11. 8 external interruptions for setting up rising- and falling-edge triggers, 1 timed interruption
12. Highly efficient command execution. LD: 0.1375μs, MOV: 2.1μs
